Belt Color Sorter Machine

Belt color sorter machines utilize a conveyor belt system to transport materials while advanced optical sensors detect and sort items based on color, shape, and size. This method is particularly effective for handling delicate or irregularly shaped products, minimizing damage during the sorting process.

Key Features

If you have any enquiry we are ready to answer

Technical Specification

This method is particularly effective for handling delicate or irregularly shaped products, minimizing damage during the sorting process.

Configuration of flexible and variable light source

Led lighting system with radiator, long service life, low energy consumption, good performance. Different raw materials require different spectra, we customize the light source according to the need of customer.

Technical Color high-resolution CCD image acquisition system

Use the color CCD image acquisition system to acquire the comprehensive information of red, green and blue color. The grain Sorter has the sensory ability of human eye, making better selection of materials , and satisfying the requirements better;
The maximum resolution is up to 0.15mm, can accurately identify small defects and spots on Raw materials, and the high-precision special lens ensures clear images.

Dedicated image processing algorithm

According to the characteristics of material, use the shape and color combination algorithm.
For materials with complex colors, the machine sorts materials more directly and accurately by using HSL-changed color space sorting method.

High-quality Ejector

Use High-quality,high-frequency,long service life ejector,super low air consumption guaranteed the biggest capacity,excellent rejection output .For the different sizes and characteristics of material particle, use the solenoid valve of different sizes.

Excellent rejection rate (with a ratio)

Advanced image acquisition system + intelligent image processing algorithms + high-quality nozzle system = excellent elimination rate

Simple operation, easy to learn and use

Simple optical system design, precise automatic correction system, combined with the well-designed human-machine interface to simplify the complexity of machine commissioning and use, ensuring the simple operation and the machine is easy to learn and use.

Specification

Model	6SXL-600
Power (kw)	2.2
Weight (kg)	1010
Power Supply (V/Hz)	220/50(110/60)
Dimension (mm)	405814822235

Material	Plastic	Peanut	Soy	Quartz Sand	Cashews	Black Tea
Product Output (t/h)	0.2-2.0	0.3-2.0	0.5-2.0	0.5-2.0	0.5-2.0	0.2-1.0
Sorting Accuracy (%)	99.3	99.5	99.8	99	99.6	99.2
Resolution (mm²)	220/50(110/60)	0.04	0.04	0.04	0.04	0.04
Optimized Carryover (Bad:Good)	3:1	6:1	5:1	3:1	4:1	2:1

Examples Of Sorting
