Advance Color Sorter Machine

Advanced color sorter machines are state-of-the-art optical sorting systems designed to identify and separate materials based on their color, shape, and size. Utilizing high-resolution cameras, AI-based image processing, and precision ejection systems, these machines ensure high sorting accuracy and efficiency.

Key Features

If you have any enquiry we are ready to answer

Technical Specification

Technical Characteristics:

HIGH RELIABILITY

With newly and more rational closed design of pulses machinery, for dust-proof this totally meet the requirements of the food machinery.The mechanical structure of pulses machinery is designed for reliability and stability, introducing the cooling system the service life and stability of the machinery . The electrical and optical design is mean for simplicity, the optimized system structure reduces the complexity of the machine,and improves the reliability of the machine

ADVANCED CAMERA IMAGE ACQUISITION SYSTEM

Use 54-pixel high resolution liner CCD image sensor and high-precision dedicated lens to receive, which can distinguish the heterochromatic of 0.04 mm2 accurately. Use the imported LED light source that features brightness, longer service life, more quality performance.

INTELLIGENT IMAGE PROCESSING ALGORITHMS

Use the intelligent algorithms to implement special treatment for the large region light yellow and spots, needle-size black specks etc.to improve sorting accuracy.

HIGH-QUALITY EJECTOR

Use High,-frequency, long service life ejecter,super long air guaranteed the biggest capacity, excellent rejection output

EXCELLENT FLIMINATION RATE(CARRYOVER RATE 10:1)

Advanced image acquisition system+intelligent image processing + high-quality nozzle system=excellent elimination rate

SIMPLE OPERATION,EASY TO LEARN AND USE

Simple optical system design, precise automatic correction system, combined with the well human-machine interface to simplify the complexity of machine commissioning and use, ensuring the simple operation and the machine is easy to learn and use

In view of the different rice, design the corresponding optimum operating mode a machine to achieve different rice color sorting

Model	6SXM- 144T	6SXM- 216T	6SXM- 288T	6SXM- 360T	6SXM- 432T	6SXM- 504T
Product Output (t/h)	1.6 ~ 5
Sorting Accuracy (%)	≥99.99	≥99.99	≥99.99	≥99.99	≥99.99	≥99.99
Carryover Rate (Bad: Good)	≥10:1	≥10:1	≥10:1	≥10:1	≥10:1	≥10:1
Weight (kg)	570	700	850	1010	1145	1265
Resolution (mm2)	0.04	0.04	0.04	0.04	0.04	0.04
Power (kw)	1.4	1.8	2.2	2.6	3.0	4.5
Dimension LWH (mmmmmm)	1149 1952 1950	1463 1952 1950	1777 1952 1950	2091 1952 1950	2405 1952 1950	1719 1952 1950
Power Supply (V/Hz)	220/50 (110/60)	220/50 (110/60)	220/50 (110/60)	220/50 (110/60)	220/50 (110/60)	220/50 (110/60)

Examples of Sorting
